TrueVue 40 Dual Reflective — Solar Control with Preserved Views
Solar Gard® TrueVue 40 is a dual-reflective architectural film designed to reject heat and glare while preserving a more neutral interior appearance. The reflective exterior helps reduce solar load, while low interior reflectance helps maintain outward visibility—especially after dark.
Key Benefits
- Reflective exterior helps maximize heat rejection and support energy savings
- Low interior reflectance helps preserve interior-to-exterior views
- Helps reduce glare on work surfaces and screens
- Blocks >99% of UV light (300–380nm) to help protect occupants and interiors
Performance Specifications — TrueVue 40
| Specification | TrueVue 40 |
|---|---|
| Visible Light Transmittance (VLT) | 39% |
| Visible Light Reflectance (Exterior) | 14% |
| Visible Light Reflectance (Interior) | 10% |
| Solar Heat Gain Coefficient (SHGC) | 0.48 |
| Total Solar Energy Rejected (TSER) | 52% |
| UV Tdw-ISO @ 300–700nm | 28% |
| UV Light Blocked (300–380nm) | >99% |
| Fade Reduction | 66% |
Roll Sizes
- 36" x 100 ft (300 sq ft)
- 48" x 100 ft (400 sq ft)
- 60" x 100 ft (500 sq ft)
- 72" x 100 ft (600 sq ft)
Performance data sourced from Solar Gard TrueVue product documentation. Actual in-field results can vary by glass type, orientation, and installation conditions.
Technical Specifications
| Specification | Value |
|---|---|
| Visible Light Transmission (VLT) | Varies by selected shade |
| Total Solar Energy Rejected (TSER) | Varies by selected film |
| Film Thickness | See product datasheet |
| Dimensions | 36" x 100 ft (300 sq ft), 48" x 100 ft (400 sq ft), 60" x 100 ft (500 sq ft), 72" x 100 ft (600 sq ft) x 100' |
Frequently Asked Questions — TrueVue 40
Yes. The Window Place USA sells Solar Gard window film by the full factory-sealed 100-foot master roll only. We do not sell partial rolls, cut pieces, or samples. Each roll ships directly from our warehouse via FedEx.
This is a material-only purchase. The Window Place USA is a wholesale distributor — we supply the film, not installation labor. Most of our customers are professional installers, contractors, facility managers, and procurement officers who arrange their own installation.
Yes. We ship to all 50 states via FedEx Ground. Government agencies, schools, and commercial buyers can use P-Card, purchase orders, or standard payment methods. We are SAM.gov registered (CAGE: 52MH9) for federal procurement.
TrueVue is a dual-reflective solar control film designed for commercial buildings, offices, schools, and residential properties where heat and glare reduction are priorities — without sacrificing outward visibility. The reflective exterior rejects solar energy, while the low interior reflectance preserves clear views, especially after dark.
Depending on the VLT (visible light transmittance) level, TrueVue films reject between 52% and 82% of total solar energy. Lower VLT numbers (like TrueVue 5) provide maximum heat and glare rejection, while higher numbers (like TrueVue 40) balance light transmission with meaningful solar control.
Dual-reflective means the film has a highly reflective exterior surface to reject solar heat, combined with a low-reflective interior surface. This prevents the mirror-like appearance from inside the building at night — a common complaint with traditional reflective films.
Both. TrueVue is widely used in commercial office buildings, government facilities, schools, and healthcare settings. It's also an excellent choice for residential homes where occupants want serious heat and glare reduction without a heavy tint appearance.
The number refers to the approximate visible light transmittance (VLT). TrueVue 40 lets in ~39% of visible light (lighter appearance, moderate solar control). TrueVue 30 lets in ~28% (balanced). TrueVue 15 lets in ~14% (strong solar control, darker). TrueVue 5 lets in ~5% (maximum heat and glare rejection, very dark). All share the same dual-reflective technology.
Professional window film installers, commercial contractors, facility managers, government procurement officers, and building owners. TrueVue is a go-to specification for energy-efficiency retrofits, tenant improvement projects, and solar control upgrades on existing glazing.
TrueVue uses dual-reflective metal technology for maximum heat rejection, while PureVue uses non-metallic ceramic technology that won't interfere with WiFi, cell signals, or GPS. TrueVue is ideal when maximum solar performance is the priority; PureVue is preferred when signal transparency and a non-reflective appearance matter most. Compare all solar control films here.
